6 – Wiring Diagrams
100-240VAC
POWER
INPUT
W
SHEET
9-D7
SHEET
5-B8
AD
AI
SHEET
5-C3
ATX DC POWER & WIRE COLOR CODE
DC COM BLK
+3.3 V ORN
+5 V RED
+5 V STAND-BY VIO
-5 V WHT
+12 V YEL
- 12 V BLU
+24 V BRN
PWR GOOD (PGD) GRY
PS_ON GRN
229348
(NOT USED)
MOTHERBORD AUX 12V DC POWER
PCB1
MOTHERBORD POWER
PCB1
229403
ATX POWER SUPPLY
BLK
GND 2
1 +5V
RED
BLK
GND +12V 5
YEL
1
2
YEL
6 +12V GND
BLK
3 7 NC NC
4 8 NC NC
ORN
+3.3V GND 24 BLK 12
YEL
+12V NC 23 11
YEL
+12V NC 22 10
VIO
+5VSB +5V 21 RED 9
GRY
PGD NC 20 8
BLK
GND GND 19 BLK 7
RED
+5V GND 18 BLK 6
BLK
GND GND 17 BLK 5
RED
+5V +S PS-ON 16 GRN 4
BLK
GND GND 15 BLK 3
ORN
+3.3V -12V 14 BLU 2
1
ORN
13 +3.3V +S +3.3V
ORN
DC OUTPUT
HARNESS
POWER DISTRIBUTION PCB
PCB2
SHEET
9-D7
W
4 3 2 1 8 7 5
D
C
B
A
8 7 5 4 3 2 1
D
C
B
A
4 3 2 1 8 7 5
D
C
B
A
8 7 5 4 3 2 1
D
C
B
A
6
6
Foglio 10 – Generatore ATX (229403)
