Caution! The pump contains oil. Do not remove the packaging keep the device in a horizontal
position at all times to avoid oil leakage from the pump.
Caution! The positioning handles must come out of the two lower holes, in order to avoid possible
damage to the plastic surface of the basin.
With the aid of the Plexiglas template, mark the fixing points for the screws on the two internal
sides of the compartment: line up the template with the front corner of the compartment and mark
the points on the front part of the eyelet, as shown in the picture.
Fix the blockage brackets (right and left) on the two internal sides of the compartment using no.8
4.5x16 screws for chipboard panels.
The brackets must rest on the horizontal surface and be vertically aligned with the two sides of the
unit.
