TABLE OF CONTENTS
CAUTION…...………………………………………………………………… p. 35
INTRODUCTION…………………………………………………………….. p. 35
FEATURES…………………………………………………………………… p. 35
SAFETY INSTRUCTIONS.…………………………………………………. p. 37
OPERATING DETERMINATIONS…..…………………………………….. p. 38
INSTALLATION..…………………………………………………………….. p. 39
Fitting / Exchanging the lamp…………………………………………. p. 39
Lamp adjustment…………..…………………………………………… p. 40
Inserting / Exchanging gobos…………………………………………. p. 41
Rigging….……………………………………………………………….. p. 42
DMX-512 connection / Connection between fixtures.……………… p. 43
Connection with the mains……………………………………………. p. 44
FUNCTION OF THE CONTROL PANEL – 16 BIT PROTOCOL……….. p. 45
FUNCTION OF THE CONTROL PANEL – 8 BIT PROTOCOL……….. p. 49
ADDRESSING……………………………………………………………….. p. 49
CONTROLLING………………………………...……………………………. p. 49
CONTROL BOARD..………………………………………………………… p. 51
ERROR AND INFORMATION MESSAGES……………………………… p. 59
TECHNICAL SPECIFICATIONS…..………………………………………. p. 62
CLEANING AND MAINTENANCE…………………………………………. p. 65
34
CAUTION!
-
Keep this device away from rain and moisture!
- Unplug mains lead before opening the housing!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP!
Every person involved with the installaition, operation and maintenance of this device
have to:
- Be
qualified
- Follow the instructions of this manual
INTRODUCTION
Thank you for having chosen a PLML575SE. You acquired a versatile, powerful and
intelligent lighting-effect.
Unpack your PLML575SE and make sure that there are no damages caused by
transportation.
Should there be any, please consult your local dealer and do not take the device into
operation.
FEATURES
Colour system: 2 colour wheels • Colour-wheel 1 with 8 different, dichroic colour-filters
and white; colour wheel 2 with 5 different, dichroic colour-filtres and white and
additionally with correction-filters 3200 K and 6000 K and UV-filter. Via the two
correction-filters, up to 64 different colours and semi-colours can be created. Rainbow-
effect in both directions. Gobo-wheel 1 with 9 static metal-gobos and open. With
goboshake function for static gobos. Gobo-wheel 2 with 3 rotating metal-gobos, 1 glass-
gobo, 2 multicolor-dichro-gobos and open. The rotating gobos can be interchanged.
High-speed rotating 3-facet prism. Remotely controllable motorized focus Combined
shutter/dimmer unit allowing very smooth dimming and strobo effect 1-10 flash per sec
Addressing, special functions setting, effects calibration via control panel with 4-digit LED
display. Readout fixture and lamp usage, receiving DMX values, temperature, etc. Built-
in analyzer for easy fault finding error messages. Remotely switching of the lamp.
Remotely switching of the lamp Macrofunction for rotating gobos/rotating prism
combinations. Black-out while Head moving or gobo/colour/prism changing. Remote
reset function. Silent fans cooling, remotely controllable speed of fans. 16 DMX channels
(16 bit Pan/Tilt movement resolution), 14 DMX-channels (8 bit Pan/Tilt movement
resolution.) Pan-movement range 530°, Tilt-movement range 280°. Automatic Pan/Tilt
position correction. High luminous-efficiency.
Motorized multi-step-zoom with three different apertures (15°, 18° and 22°). Steplessly
adjustable iris; preprogrammed variable/random iris pulse effects 14 high-quality
stepper-motors for smooth movements. Self-resetable thermo-fuse. Lamp HSR575.
Standard DMX controller.
