- ENGLISH -
- 41 -
REGISTER
(1)
STS - COMMANDS
UNIT
NUMBER
ADDRESS
113
112
Command code
(2)
Integer
114
113
User password
Integer
115
114
116
115
117
116
Command result
(3)
Integer
118
117
REGISTER
(1)
DIAGNOSTIC
UNIT
NUMBER
ADDRESS
119
118
Counter of processed correct messages
Integer
120
119
Counter of processed NOT correct messages
Integer
121 128
120 127
REGISTER
(1)
MultiCOM DATA
UNIT
NUMBER
ADDRESS
129
128
Firmware version
Integer*100
130 131
129 130
(1)
The register number n must be addressed n-1 in the data packet
(2)
Refer to “Command codes” paragraph
(3)
Command result = Command code if command is handled from the STS
Command result = 0 if Command code is wrong
STS:
C
OMMANDS CODES
Before running the commands, you must log in (command code 8) with the correct
password (Register address 114).
CODE
COMMAND
4
(0x0004)
Beeper disable
5
(0x0005)
Beeper enable
8
(0x0008)
Log In
9
(0x0009)
Log Out
17 (0x0011)
Cancel manual transfer
18 (0x0012)
Manual transfer to source 1
19 (0x0013)
Manual transfer to source 2
21 (0x0015)
Test General
22 (0x0016)
Test Panel
23 (0x0017)
Test Cancel
Commands are not supported by the ATS
