- ENGLISH -
- 38 -
STS: T ABLES OF STATES , MEASUREMENTS , NOMINAL DATA AND COMMANDS
REGISTER
(1)
STS/ATS - STATES
BIT
(2)
NUMBER ADDRESS NUMBER ADDRESS
1 0
Sound Off [0=No / 1=Yes] 1 0
Test in progress [0=No / 1=Yes] 2 1
Reserved 3 2
Reserved 4 3
Aux. Power2 failure [0=No / 1=Yes] 5 4
Aux. Power1 failure [0=No / 1=Yes] 6 5
Synchron bad [0=No / 1=Yes] 7 6
Preferred Source [0=S1 / 1=S2] 8 7
Transfer inhibit [0=No / 1=Yes] 9 8
Non Synch. inhibit [0=No / 1=Yes] 10 9
Source S2 bad [0=No / 1=Yes] 11 10
Source S1 bad [0=No / 1=Yes] 12 11
On Source S2 [0=No / 1=Yes] 13 12
On Source S1 [0=No / 1=Yes] 14 13
ATS/STS Locked [0=No / 1=Yes] 15 14
Output Switch Off [0=No / 1=Yes] 16 15
2 1
S2 Black Out [0=No / 1=Yes] 17 16
Always zero 18 17
S2 Phase sequency not OK [0=No / 1=Yes] 19 18
S2 Voltage out of tolerance [0=No / 1=Yes] 20 19
S1 SCR alternance loss [0=No / 1=Yes] 21 20
S1 Input SW Off [0=No / 1=Yes] 22 21
S1 Frequency bad [0=No / 1=Yes] 23 22
S1 Balance bad [0=No / 1=Yes] 24 23
S1 Black Out [0=No / 1=Yes] 25 24
Always zero 26 25
S1 Phase sequency not OK [0=No / 1=Yes] 27 26
S1 Voltage out of tolerant [0=No / 1=Yes] 28 27
User Login [0=No / 1=Yes] 29 28
Alarm Overtemp. [0=No / 1=Yes] 30 29
Alarm Overload [0=No / 1=Yes] 31 30
General Failure [0=No / 1=Yes] 32 31
(1)
The register number n must be addressed n-1 in the data packet.
(2)
The bit number n must be addressed n-1 in the data packet.
