- ENGLISH -
- 39 -
REGISTER
(1)
STS/ATS - STATES
BIT
(2)
NUMBER ADDRESS NUMBER ADDRESS
3 2
Always zero 33 32
Always zero 34 33
Always zero 35 34
Always zero 36 35
S2 Input MCCB trip [0=No / 1=Yes] 37 36
S1 Input MCCB trip [0=No / 1=Yes] 38 37
Service Login [0=No / 1=Yes] 39 38
Output SCR alternance loss [0=No / 1=Yes] 40 39
Maintenance Bypass to S2 [0=No / 1=Yes] 41 40
Maintenance Bypass to S1 [0=No / 1=Yes] 42 41
Manual Transfer on S2 [0=No / 1=Yes] 43 42
Manual Transfer on S1 [0=No / 1=Yes] 44 43
S2 SCR alternance loss [0=No / 1=Yes] 45 44
S2 Input SW Off [0=No / 1=Yes] 46 45
S2 Frequency bad [0=No / 1=Yes] 47 46
S2 Balance bad [0=No / 1=Yes] 48 47
4 3
49 48
50 49
51 50
52 51
53 52
54 53
55 54
56 55
57 56
58 57
59 58
60 59
61 60
62 61
63 62
Communication lost with STS [0=No / 1=Yes] 64 63
5 8 4 7 65 128 64 127
(1)
The register number n must be addressed n-1 in the data packet.
(2)
The bit number n must be addressed n-1 in the data packet.
