- ENGLISH -
- 36 -
REGISTER
(1)
UPS – NOMINAL DATA UNIT
NUMBER ADDRESS
73 77 72 76
78 77 Output nominal voltage (star) V
79 78 Output nominal frequency 0.1*Hz
80 79 Output nominal power 100*VA
81 83 80 82
84 83 Battery nominal capacity (battery expansion included) Ah
85 84 Battery benches (1 or 2)
86 85 Battery type Integer
87 112 86 111
REGISTER
(1)
UPS - COMMANDS UNIT
NUMBER ADDRESS
113 112 Command code
(2)
Integer
114 113 Shutdown delay time Seconds
115 114 Restore delay time Minutes
116 115
117 116 Command result
(3)
Integer
118 117
REGISTER
(1)
DIAGNOSTIC UNIT
NUMBER ADDRESS
119 118 Counter of processed correct messages Integer
120 119 Counter of processed NOT correct messages Integer
(1)
The register number n must be addressed n-1 in the data packet.
(2) Refer to “Command codes” paragraph
(3)
Command result = Command code if command is handled from the UPS
Command result = Command code + 100 if command is NOT handled from the UPS
Command result = 0 if Command code is wrong
