Ommands codes – Riello UPS MultiCOM 301/302 Manuale d'uso
Pagina 37
- ENGLISH -
- 37 -
REGISTER
(1)
SPECIAL FLAGS (SENTR UPS)
(2)
UNIT
NUMBER
ADDRESS
121
120
Byte 1 of “s = xx..” code / Byte 2 of “s = ..xx” code
Flag
122
121
Byte 1 of “c = xx..” code / Byte 2 of “c = ..xx” code
Flag
123
122
Byte 1 of “b = xx..” code / Byte 2 of “b = ..xx” code
Flag
124
123
Byte 1 of “r = xx..-..” code / Byte 2 of “r = ..xx-..” code
Flag
125
124
Byte 3 of “r = ....-xx” code / Byte 1 of “i = xx..-..” code
Flag
126
125
Byte 2 of “i = ..xx-..” code / Byte 3 of “i = ....-xx” code
Flag
127
126
Byte 1 of “a = xx..-....” code / Byte 2 of “a = ..xx-....” code
Flag
128
127
Byte 3 of “a = ....-xx..” code / Byte 4 of “a = ....-..xx” code
Flag
REGISTER
(1)
DATI DEL MultiCOM
UNIT
NUMBER
ADDRESS
129
128
Firmware version
Integer*100
130ч131
129ч130
(1)
The register number n must be addressed n-1 in the data packet.
(2)
In order to decode these registers, please refer to the UPS manual.
UPS:
C
OMMANDS CODES
CODICE
COMANDO
1
(0x0001)
Command Shutdown
2
(0x0002)
Command Shutdown and Restore
3
(0x0003)
Delete Command (code 1, 2, 12)
12 (0x000C)
UPS on Bypass
20 (0x0014)
Test Battery
22 (0x0016)
Test Panel
