Values displayed
in the NOW menu
item
Values displayed
in the LOG menu
item
Output power (W) - depending on the device type (MultiString), two output powers (PV1
/ PV2 ) are displayed when the Enter key is pressed
AC reactive power (VAr)
Grid voltage (V)
Output current (A)
Grid frequency (Hz)
PV array voltage (V) - from U PV1 and U PV2 if present
PV array current (A) - from I PV1 and I PV2 if present
Fronius Eco: The total current from both measuring channels is displayed. Both channels
are shown separately in SolarWeb.
Time date - Time and date on the inverter or in the Fronius Solar Net ring
Energy fed in (kWh / MWh)
Energy fed into the grid during the period in question
There may be discrepancies with values displayed on other measuring instruments be-
cause of differences in measuring methods. As far as the billing of the energy fed in is
concerned, the only binding display values are those produced by the calibrated measur-
ing device provided by the electricity supply company.
Max. output power (W)
Largest amount of energy fed into the grid during the period in question
Yield
Amount of money earned during the period in question (currency and conversion factor
can be selected in the Setup menu)
Like the energy supplied figure, the yield figure may also exhibit discrepancies with other
measured values.
The 'Setup Menu' section explains how to select a currency and charge rate.
The factory setting depends on the respective country setup.
Max. AC grid voltage (V)
Highest AC grid voltage measured during the period in question
Maximum solar voltage (V)
Highest solar module voltage measured during the period in question
Operating Hours
Length of time the inverter has been working (HH:MM).
IMPORTANT! A prerequisite for the correct display of day and year values is that the time
is set correctly.
