58
Fronius Symo
dummy
Explanation of
footnotes 1) The values stated are defaults; the inverter is configured specifically to suit the re-
quirements of the relevant country.
2) Depending on the country setup or device-specific settings
(ind. = inductive; cap. = capacitive)
3) PCC = interface to the public grid
4) Maximum current from the inverter to the solar module when an error occurs in the
inverter
5) Guaranteed by the electrical configuration of the inverter
6) Current peak when switching on the inverter
Applicable stand-
ards and guide-
lines CE mark
The devices comply with all the requisite and relevant standards and guidelines that form
part of the relevant EU Directive, and are therefore permitted to display the CE mark.
Circuit to prevent stand alone operation
The inverter has an approved circuit to prevent stand alone operation.
Grid failure
The standard measurement and safety procedures integrated into the inverter ensure that
in the event of a grid failure, the feed-in of energy is immediately interrupted (e.g. switch-
off by the energy supplier or damage to lines).
Input data Dummy 3 - 10 kW Dummy 10 - 20 kW
Nominal grid voltage 1 ~ NPE 230 V
Grid voltage tolerance +10 / -5 %
1)
Nominal frequency 50 - 60 Hz 1)
General data
Degree of protection
IP 65 IP 66
Dimensions h x w x d 645 x 431 x 204 mm 725 x 510 x 225 mm
Weight 11 kg 22 kg
