- ENGLISH -
11
ENGLISH
1 PRESENTATION
KIT CONTENTS
ESD/Contacts port adapter card
Metal slot cover
This manual
DESCRIPTION AND CHARACTERISTICS
The ESD/Contacts port card is installed in the appropriate slot on the rear of the UPS.
The card has two removable terminal boards. One of these terminal boards has the
ESD signal (UPS Emergency ShutDown) and the RSD signal (Remote ShutDown).
Other signals can also be associated with the card, such as Battery Working, Bypass,
Alarm and Battery Low, through zero-potential switchover or normally open contacts.
WARNING: the contacts inside the board capable of carrying a max. current of
3A at 250Vac
Figure 1: Allocation of setting points and the terminal boards
JP2
JP1 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1
1
2
3
JP4
1
2
3
JP3
4
3
2
1
8
7
6
5
4
3
2
1
J1
J3
