SPECIFICATIONS
Acoustical specifications
Frequency Response:
45 Hz ÷ 20000 Hz
Max SPL @ 1m:
135 dB
Coverage angle:
100°H x 25°V (TTL 4-A; TTL C4-A)
100°H x 50°V (TTW 4-A; TTW C4-A)
600°H x 25°V (TTP 4-A; TTP C4-A)
Transducers
Compression Driver:
1 x 1.5'' neo, 4.0'' v.c
Woofer:
2 x 10'' neo, 3.0'' v.c
Input/Output section
Input signal:
bal/unbal
Input connectors:
XLR, RDNet Ethercon
Output connectors:
XLR, RDNet Ethercon
Input sensitivity:
+4 dBu
Processor section
Crossover Frequencies:
900Hz
Protections:
Thermal, RMS
Limiter:
Fast Limiter
Controls:
Selectable preset, volume, delay
RDNet:
Yes
Power section
Total Power:
3200 W Peak, 1600 W RMS
High frequencies:
1200 W Peak, 600 W RMS
Low frequencies:
2000 W Peak, 1000 W RMS
Cooling:
Convection
Connections:
Powercon IN/OUT
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Baltic birch plywood
Hardware:
Array fittings, 2xM10 on the top, 2xM8
Handles:
2 side, 2 rear
Pole mount/Cap:
Yes
Grille:
Steel
Color:
Black
Size
Height:
825 mm / 32.48 inches
Width:
316 mm / 12.44 inches
Depth:
369 mm / 14.53 inches
Weight:
30.4 kg / 67.02 lbs
Shipping informations
Package Height:
410 mm / 16.14 inches
Package Width:
865 mm / 34.06 inches
Package Depth:
365 mm / 14.37 inches
Package Weight:
33.5 kg / 73.85 lbs
