24
EN
LINKING THE FLYBAR TO THE SPEAKER (HORIZONTAL CONFIGURATION)
Place the Flybar over the speaker by matching the two lateral brackets, then insert the quick lock pin on both sides�
9.1 LINKING TWO OR MORE SPEAKERS TOGETHER (HORIZONTAL CONFIGURATION)
To link two or more speakers together in horizontal configuration, raise the lateral bracket on one speaker and insert it to the corresponding seat
on the other speaker; then secure it by inserting the quick lock pin�The same operation must be done on both sides of the speaker�
PART 2 | 9. SUSPENDED CONFIGURATIONS
TTL C4-A, TTP C4-A, TTW C4-A
