Advanced Contact Technology
www.multi-contact.com 3 / 12
1
2
3
1
2
3
4
4
1
2
3
4
(ill. 1 + 2)
Guscio presa completo
RobiFix-B35-MTB,
n. ordine 30.4005
I contatti sono inclusi
(ill. 1 + 2)
Socket housing complete
RobiFix-B35-MTB,
Order No. 30.4005
Contacts are included in the delivery
RobiFix-ZE Pressacavo
N. ordine 30.4031(compreso nella
fornitura)
1) Vite M5 a brugola
2) Pressacavo
3) Pressacavo
4) Dado esagonale M5
Cable strain relief
Order No. 30.4031 (supplied)
1) Assembly screw M5 for Allen key
2) Cable strain relief (upper)
3) Cable strain relief (lower)
4) Hexagonal nut M5
(ill. 3 + 4)
Guscio spina completo
RobiFix-S35-MTB,
N. ordine 30.4010
I contatti sono inclusi
(ill. 3 + 4)
Pin housing complete
RobiFix-S35-MTB,
Order No. 30.4010
Contacts are included in the delivery
RobiFix-ZE Pressacavo
N. ordine 30.4031 (compreso nella
fornitura)
1) Vite M5 a brugola
2) Pressacavo
3) Pressacavo
4) Dado esagonale M5
Cable strain relief
Order No. 30.4031
1) Assembly screw M5 for Allen key
2) Cable strain relief
3) Cable strain relief
4) Hexagonal nut M5
