18
Thank you for choosing this Proel product and for trusting our brand, which strives to be synonymous with
professionalism, precision, high quality and reliability. All of our products comply with EC regulations regarding audio
equipment for continuous use.
2. DESCRIPTION
Wireless conference system is composed by a receiver unit referred DWS, four wireless stands BMW and a
battery charger.
The system is UHF PLL and is equipped with an anti- interferences system and TONE LOCK.
2 Frequencies range are available within the following bands : a: 610÷ 670 MHz and b:730÷ 790MHz
For each frequency range 3 receivers units for a maximum of 12 microphone units. When both range of
frequencies are used, we can obtain up to 6 receivers units (3 from one frequency range and 3 from the other ) for a
maximum of 24 microphone units (12 with set up on the frequency range of the type a and 12 of the type b ) working
contemporaneously.
Each central unit features 4 channels:
Range a:
Channel A: band 610.00 ÷ 624.75 MHz
Channel B: band 625.00 ÷ 639.75 MHz
Channel C: band 640.00 ÷ 654.75 MHz
Channel D: band 655.00 ÷ 669.75 MHz
Range b:
Channel A: band 730.00-744.75MHz
Channel B: band 745.00-759.75MHz
Channel C: band 760.00-774.75MHz
Channel D: band 775.00-789.75MHz
Each stand BMW is operating exclusively on one of the fourth frequency ranges ( you can easily read on each stand
rear back (fig.3, ref.11). The stand power supply is effected through a couple of rechargeable AA 1,2V 1200mA
batteries or in alternative a couple of normal disposable AA,1,5 V batteries.
Note: the batteries timing is 8-9 h when the Tx power selector is on Hi position or 10-11 h when the selector is on Lo
position.
Main features:
•
Dual display
• Keys for navigation
•
Single level control for each stand
• Infrared technology for operating frequency set up
•
Balanced output and mixed unbalanced output
• Single output for each channel
•
Channel or Tuning frequency mode
• Squelch control separately and for each single stand
•
Wireless console with display and light ring to indicate operating condition
• Range 50/60 mt
•
Case in metal one unit 19” rack standard
Product complies with CE regulations
