Technical Specifications
Section
Technical Specifications Connections
MONO INPUT CHANNEL
Mic Input
sensitivity -0 to -60 dB XLR-F, balanced
impedance 2 Kohm
Line Input sensitivity +20 a -40 dB TRS Jack, Bal/Unbalanced
impedance 10 Kohm
EQ HI ±15 dB @ 12KHz shelving
MID ±15 dB @ 2.5KHz peaking
LOW ±15 dB @ 80Hz shelving
STEREO INPUT CHANNEL
Mic Input
sensitivity from 0 to -40dB XLR-F, balanced
impedance 2 Kohm
Line Input sensitivity from +20 to -20dB TRS Jack, Bal/Unbalanced
impedance 10 Kohm
EQ HI ±15 dB @ 12KHz shelving
MID ±15 dB @ 2.5KHz peaking
LOW ±15 dB @ 80Hz shelving
MASTER SECTION
MASTER & ALT3-4
Nominal output level +4 dBu TRS Jack, Balanced
C. ROOM output Nominal output level +4 dBu TS Jack, Unbalanced
AUX 1 OUT Nominal output level +4 dBu TS Jack, Unbalanced
AUX 2 OUT Nominal output level +4 dBu TS Jack, Unbalanced
2-TRK OUT Nominal output level 0 dBu Rca Unbalanced
2 TRK IN Nominal input level. -10 dBv Rca Unbalanced
PHONES Minimum load impedance 32 ohm Jack Stereo
Maximum output level (2x) 193 Mw
DIGITAL EFFECT PROCESSOR
Preset
HALL, ROOM, VOCAL e PLATE reverbs
STEREO, MONO & TAP DELAYS
CHORUS & FLANGER MODULATIONS
REV + STEREO DELAY, MONO DELAY, CHORUS, FLANGER combinations
GENERAL SPECIFICATIONS
Maximum Output Level – All Outputs +22 dBu
Crosstalk @1 KHz > 82 dBu
Signal/Noise ratio - unweighted < -93 dBu
THD + noise at +4dB, 1kHz < 0,008 %
Weight 3.1 Kg
Dimensions (LxAxP) 27.8 x 35.1 x 8.5 cm
POWER REQUIREMENTS
AC Supply
18 V AC 1200mA. NOTE: use only the supplied AC/AC ADAPTER
Mains Supply Europe 230 V AC (±10 %) 50 / 60 Hz
Consumption 69 VA
