TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response:
70 Hz ÷ 20000 Hz
Max SPL @ 1m:
127 dB
Horizontal coverage angle:
100°
Vertical coverage angle:
70°
Transducers
Compression Driver:
1 x 1.0'' neo, 1.75'' v.c
Woofer:
2 x 5.0'' neo, 2.0'' v.c
Input/Output section
Input signal:
bal/unbal
Input connectors:
XLR, RDNet Ethercon
Output connectors:
XLR, RDNet Ethercon
Input sensitivity:
-2 dBu/+4 dBu
Processor section
Crossover Frequencies:
1200
Protections:
Excurs.
Limiter:
Fast Limiter
Controls:
Bypass, Linear/High Pass, Volume, RDnet
on boar
RDNet:
Yes
Power section
Total Power:
2000 W Peak, 1000 W RMS
High frequencies:
600 W Peak, 300 W RMS
Low frequencies:
1400 W Peak, 700 W RMS
Cooling:
Convection
Connections:
Powercon IN/OUT
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Baltic birch plywood
Hardware:
2X M10 TOP AND BOTTOM
2X PIN D.10
Handles:
2 TOP AND BOTTOM
Grille:
Steel
Color:
Black
Size
Height:
456 mm / 17.95 inches
Width:
154 mm / 6.06 inches
Depth:
237.5 mm / 9.35 inches
Weight:
9.8 kg / 21.61 lbs
Shipping informations
Package Height:
510 mm / 20.08 inches
Package Width:
290 mm / 11.42 inches
Package Depth:
200 mm / 7.87 inches
Package Weight:
11.3 kg / 24.91 lbs
SPECIFICATIONS / SPECIFICHE
