Capitolo 5 ALTRE FUNZIONI UTILI
5-59
3 Premere il tasto “2 sided copy”, quindi il tasto “Open from left”
[“Left binding”]. Infine, premere il tasto “Close”. Il pannello a
sfioramento tornerà alla schermata visualizzata al punto 2.
Specifiche in pollici
Specifiche metriche
4 Premere il tasto “Edit”. Nella schermata visualizzata, premere
il tasto “Modify Copy”. Verrà visualizzata la schermata “Modify
Copy”.
Specifiche in pollici
Specifiche metriche
5 Premere il tasto “On”.
Premere il tasto “Close”. Il pannello a sfioramento tornerà alla
schermata visualizzata al punto 4.
Specifiche in pollici
Specifiche metriche
● Selezionare le impostazioni per il primo originale (“A” nell’illustrazione
a pagina 5-58).
Nella schermata “Select paper” è necessario selezionare per
l’alimentazione della carta colorata il vassoio multi-bypass.
6 Premere il tasto “Select paper”. Verrà visualizzata la
schermata “Select paper”.
Specifiche in pollici
Specifiche metriche
1 sided/ 2 sided copy
1 sided
copy
2 sided
copy
Open from
left
Open from
right
Finished
Open from
top
Check direction
Check direction of
original top side.
Ready to Job build.
Place originals then press Start key.
Close Back
Set
Back Edge
Left top
corner
1-sided / 2-sided Copy
1-sided
Copy
2-sided
Copy
Left
binding
Right
binding
Finished
Top
binding
Ready to Job build.
Set original. Press Start key.
Close Back
Set
Back Edge
Left top
corner
Check direction
Check direction of original.
Border
Erase
Auto
Tray A
Modify
Copy Select
orig.size
Select of
Output
None
Page #
Margin/
Centering
None
Off Off
2 sided copy-Left
Finished page # : 0
Basic Quality Edit
Job Build - Step1 End
Insert page
Ready to Job build.
Place originals then press Start key.
Set
Print from
Rear page
Erase Mode
Auto None None
Finisher main tray
Modify copy
Select of
Output
Select size
original
None None
Page
numbering Margin/
Imag.shift
2-sided Copy-Left
Finished page #: 0
Basic Quality Edit
Job Build - Step1 End
Ready to Job build.
Set original. Press Start key.
Set
Insert
blank page
Print from
Rear page
Modify copy
Off
On
When the mode is set [On], it can
save a job data and reprint it anytime.
And you can set that other user are not
able to reprint.
Ready to Job build.
Set original. Press Start key.
Close Back
Set
When select [On], job can be saved.
You can recall and re-print at anytime.
You can set a password to secure saved
document.
Ready to Job build.
Place originals then press Start key.
1-sided 2 sided copy
Back Edge
1 sided/
2 sided
2 sided copy-Left
Finished page #:0
Orig. set
direction
Original
type
AMS
Reduce
/Enlarge
Finished
Basic Quality Edit
None
Job Build - Step3 End
Insert
page
Set
Select
paper
11x8 1 / 2
Print from
Rear page
Ready to Job build.
Set original. Press Start key.
1-sided 2-sided Copy
Back Edge
1-sided/
2-sided
2-sided Copy-Left
Finished page #: 0
Orig. set
direction
Original
type
AMS
Reduce/
Enlarge
Finished
Basic Quality Edit
None
Job Build -Step 3 End
Set
Select
paper
Insert
blank page
Print from
Rear page
Ready to Job build.
Place originals then press Start key.
Modify Copy
Off
On
Set
Close Back
W h e n s e l e c t [ O n ] , d a t a c a n b e s a v e d .
Yo u c a n r e c a l l a n d r e - p r i n t a t a n y t i m e .
A n d y o u c a n s e t t h e p a s s w o r d t o s e c u r e
s a v e d d o c u m e n t .
