MAIN GUIDELINES
-
Do not mount the luminaire near a flammable surface.
-
Use the luminaire in dry locations only, where humidity does not exceed 90 percent.
-
The luminaire is for indoor use only and is not intended for outdoor use.
-
For temporary installations, mount and support the luminaire only by the primary suspension
yoke holes. Suspend the luminaire from a hook clamp (PLH295-PLH300 optional).
-
In addition to primary suspension, use a steel safety cable (PLH200 optional) to the secondary
suspension point.
-
If the external cable is damaged, it shall be replaced by our service agents.
-
Always hang the luminaire with the colour frame held securely behind the retaining clip.
-
Always replace the lamp if it becomes damaged or thermally deformed.
-
Disconnect the unit from power before all cleaning and maintenance.
-
The luminaire is suitable for indoor use with a maximum ambient temperature: Ta=45°C
-
Maximum exterior surface temperature: T
max
: 250°C.
-
Keep the luminaire at least 2.5 meters away from any lit surface.
LUMINAIRE INFORMATION
A plug of at least 2.5 amp (220/240V) rating should be attached to the luminaire’s mains lead. The
wires in the mains lead are 1.55mm2 each and coloured in accordance with the following code:
GREEN/YELLOW: Ground
BLUE:
Neutral
BROWN: Live
WARNING: the luminaire must be earthed
Current rating:
5A max./120V
2,5A max./230V
Operating frequency:
50/60Hz
Lamp type:
HPL 575/750W
