WARNING: Unplug the luminaire before attempting to clean the reflector.
To quickly clean the reflector, remove the lens tube and clean the dust from the reflector with a
blast of oil-free air. You may also wipe the reflector with a clean lint-free cloth. If either method
is not sufficient, follow these steps.
1. To protect the lamp housing during cleaning, remove the lamp housing.
2. Remove the barrel rotation knob located at the bottom of the barrel. Use a Phillips screwdriver
to remove the retainer bolt located on top of the reflector housing.
3. Rotate the barrel 45° in either direction. Carefully remove the barrel from the reflector
housing.
4. Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl alcohol,
distilled water or a 50%-50% mixture of each can be used to clean the glass surface.
5. Gently wipe the reflector.
6. Insert the barrel into the reflector housing with the iris/pattern slot on top.
7. Reinstall the barrel rotation knob and tighten the retainer bolt.
8. Reinstall the lamp housing and tighten the knurled bolt.
TECHNICAL DATA
PLHT575PF30 PLHT575PF25
Power supply: 230V-50Hz / 120V-60Hz Power supply: 230V-50Hz / 120V-60Hz
Lamp: HPL 575/750W Lamp: HPL 575/750W
Code: PLLP575HTC / PLLP750HTC Code: PLLP575HTC/PLLP750HTC
Zoom: from 15° to 30° Zoom: from 25° to 50°
Dimensions: LxWxH mm.210x800x295 Dimensions: LxwxH mm.210x700x295
Weight: kg. 10,2 Peso: kg. 9,4
