10
OPERATING INSTRUCTIONS
BATTERY REPLACEMENT
For the Battery replacement use always 2x 1.5V AA size LITHIUM or ALKALINE type for the best
performances. You can use also rechargeable batteries but in this case the operating time is shorter.
Good quality ALKALINE batteries guarantee an operating time of about 6Ͳ8 hour.
To replace the batteries in the RM3000R bodypack receiver slide down the battery cover (20) and
insert the batteries following always the polarity marked inside the battery inlet.
IMPORTANT!
Always remember to remove the batteries if you don’t use the bodypack receiver: this
will avoid the corrosion of the contacts and the battery consumption.
SETTING UP A SINGLE SYSTEM
Press on the RM3000R bodypack receiver: the LCD appears ,then check the
RF signal on antenna symbol:
x If there is no RF signal
and the RM3000 transmitter is switched OFF, turn it on
then check again: RF signal must be present and the RF LED is on. If the
RF signal is still not present, check the transmitter and receiver channel correspondence:
x If there is RF signal
and the RM3000 transmitter is switched OFF, there is probably
another equipment transmitting on the same channel, so you have to change the receiver
channel:
press and hold the up button
then press two times until the channel flashing
then using and buttons select another channel.
Switch on the transmitter
press and hold a CHANNEL SELECT (15) button, until the display (16) flashing,
then press again one of the CHANNEL SELECT (15) button to choose the same channel
selected previously on the receiver, both channels must be the same:
x If you don’t press any button within 5 seconds, the receiver or the transmitter goes back to
normal operation.
