4
MODEL MLX2842/MLX3642 Connectors MODELLO MLX2842/MLX3642 Connettori
MONO INPUT CHANNELS CANALI INGRESSO MONO
Mic Input Sensitivity from 0 to -50 dBu
Balanced XLR-F
Sensibilità Ingresso Mic da 0 a -50 dBu
XLR-F Bilanciato
Mic Input Impedance 2 Kohm Impedenza Ingresso Mic 2 Kohm
Line Input Sensitivity from +15 to -35 dBu
Balanced Jack
Sensibilità Ingresso Line da +15 a -35 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
LO CUT 75Hz, 18dB/oct. FILTRO LO-CUT 75Hz, 18dB/oct.
EQ HIGH (shelving) ±15 dB @ 12K Hz EQ ALTI (shelving) ±15 dB @ 12K Hz
HI-MID (peaking) ±15 dB 500-12K Hz MEDIO-ALTI (peaking) ±15 dB 500-12K Hz
LO-MID (peaking) ±15 dB 80-2K Hz MEDIO-BASSI (peaking) ±15 dB 80-2K Hz
LOW (shelving) ±15 dB @ 80 Hz BASSI (shelving) ±15 dB @ 80 Hz
INSERT nom. out level 0 dBu TRS Jack INSERT livello nominale 0 dBu Jack TRS
DIRECT OUT max. level +22 dBu Unbalanced Jack DIRECT OUT livello max +22 dBu Jack Bilanciato
STEREO INPUT CHANNELS CANALI INGRESSO STEREO
Line Input Sensitivity from +15 to -35 dBu
Balanced Jack
Sensibilità Ingresso Line da +15 a -35 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
EQ HIGH (shelving) ±15 dB @ 12K Hz EQ ALTI (shelving) ±15 dB @ 12K Hz
HI-MID (peaking) ±15 dB @ 3 KHz MEDIO-ALTI (peaking) ±15 dB @ 3 KHz
LO-MID (peaking) ±15 dB @ 500 Hz MEDIO-BASSI (peaking) ±15 dB @ 500 Hz
LOW (shelving) ±15 dB @ 80 Hz BASSI (shelving) ±15 dB @ 80 Hz
MASTER SECTION SEZIONE MASTER
MAIN MIX max out level +28 dBu Balanced XLR-M MAIN MIX livello max +28 dBu XLR-M Bilanciato
GROUP max out level +28 dBu Balanced Jack GROUP livello max +28 dBu Jack Bilanciato
INSERT nom. out level 0 dBu TRS Jack INSERT nom. out level 0 dBu Jack TRS
AUX max out level +28 dBu Balanced XLR-M AUX livello max +28 dBu XLR-M Bilanciato
EQ HIGH (shelving) ±15 dB @ 12K Hz EQ ALTI (shelving) ±15 dB @ 12K Hz
MID (peaking) ±15 dB 500-12K Hz MEDI (peaking) ±15 dB 500-12K Hz
LOW (shelving) ±15 dB @ 80 Hz EQ BASSI (shelving) ±15 dB @ 80 Hz
MONITOR max out level +22 dBu Unbalanced Jack MONITOR livello max +22 dBu Unbalanced Jack
2 - TRK max out level +22 dBu Unbalanced Rca Livello max 2 - TRK OUT +22 dBu Rca Sbilanciato
2 - TRK nom. in level +22 dBu Unbalanced Rca Livello max 2 - TRK IN +22 dBu Rca Sbilanciato
PHONES max. out level 193 mW @ 32 ohm Stereo Jack Livello max PHONES 193 mW @ 32 ohm Jack Stereo
USB IN/OUT, 16bit / 48KHz Type B USB IN/OUT, 16bit / 48KHz Tipo B
DIGITAL EFFECT PROCESSOR - PROFEX DIGITAL EFFECT PROCESSOR - PROFEX
Equipped Effects 2 Effetti integrati 2
Presets 256 (16 presets x 16 variations) Presets 256 (16 preset x 16 variazioni)
A/D, D/A, DSP resolution 24 bit Risoluzione A/D, D/A, DSP 24 bit
Controls 2-digit display, PRESET dial, TAP DELAY, MUTE Controlli 2 display LED, PRESET, TAP DELAY e MUTE
GENERAL MLX2842 MLX3642 GENERALI MLX2842 MLX3642
Crosstalk meas. at 1 KHz > 80 dB Diafonia mis. a 1 KHz > 80 dB
HUM & N unweighted < -93 dBu HUM & N non pesato < -93 dBu
THD+N at +20dBu, 1kHz < 0,03 % THD+N a +20dBu, 1kHz < 0,03 %
Dimensions (W x H x D) 900 x 170 x 515 mm 1125 x 170 x 515 mm Dimensioni (L x A x P) 900 x 170 x 515 mm 1125 x 170 x 515 mm
Weight 17.2 kg 21.1 kg Peso 17.2 kg 21.1 kg
POWER REQUIREMENTS MLX2842 MLX3642 ALIMENTAZIONE MLX2842 MLX3642
Mains Supply Voltage: 100-240 VAC (±10%) 50 / 60 Hz
available with Europe mains cord (Shucko plug),
US mains cord (NEMA 5-15P plug),
UK mains cord (BS1363 plug)
Tensione di Rete: 100-240 VAC (±10%) 50 / 60 Hz
disponibile con cavo rete Europa (spina Shucko),
cavo rete Stati Uniti (spina NEMA 5-15P),
cavo rete Regno Unito (spina BS1363)
Consumption 75 W 90 W Assorbimento 75 W 90 W
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
