Technical Characteristics
The product is in compliance with Directive 89/336/EEC (Electromagnetic Compatibility)
and following modifications 92/31/EEC and 93/68/EEC, as the following standards:
EN 50082-1:1997, EN 55013:1990, EN 55020:1994
it is also in compliance with Directive 73/23/EEC (Low Voltage)
and following modifications 93/68/EEC, as the following standard:
EN 60065:1998
MODEL AUP120R AUP240R AUP480R
Output Power RMS 120/180MAX 240/360MAX 480/680MAX
INPUTS
Line input
100mV-500mV-
1V/47Kohm select. 100mV-500mV-
1V/47Kohm select. 100mV-500mV-
1V/47Kohm select.
Telephone/Emergency
Variable gain -
600ohms Variable gain -
600ohms Variable gain -
600ohms
Microphone for Paging Variable gain - with
priority contact Variable gain - with
priority contact Variable gain - with
priority contact
Frequency range (+/-
3dB) 50 -20KHz 50 -20KHz 50 -20KHz
Tone Control Low/High Low/High Low/High
OUTPUTS
Speakers (Music and
speech) 100/70/50V - 8 ohms 100/70/50V - 8 ohms 100/70/50V - 8 ohms
Speakers (only speech) 100V 100V 100V
Wall attenuators 24Vdc for bypass 24Vdc for bypass 24Vdc for bypass
Line output 1 V/600ohm 1 V/600ohm 1 V/600ohm
THD distortion < 1% @ (Pnom. 1Kz) < 1% @ (Pnom. 1Kz) < 1% @ (Pnom. 1Kz)
S/N Ratio > 80 dB > 80 dB > 80 dB
Power Supply 230/117Vac-50/60Hz
24Vdc for Emergency 230/117Vac-50/60Hz
24Vdc for Emergency 230/117Vac-50/60Hz
24Vdc for Emergency
Ambient temperature 0 - 40 °C 0 - 40 °C 0 - 40 °C
19” RACK Dimensions
(WxHxD) 483 x 88 x 300 mm 483 x 88 x 300 mm 483 x 133 x 300 mm
Weight 10 Kg 13 Kg 25 Kg
INPUT/OUTPUT
CONNECTORS
Line IN/Line out 2 x XLR and 1 RCA
L/R each 2 x XLR and 1 RCA L/R
each 2 x XLR and 1 RCA
L/R each
Others in/out screw terminal screw terminal screw terminal
Proel SpA pursue a policy of continuous research and development. Proel SpA reserve the right to modify
product circuitry and appearance at any moment, without prior notice.
