Thank you for choosing one of Proel products, and for your confidence towards
our brand, synonymous of professionalism, accuracy, high quality and reliability.
All our products are CE approved and designed for continuous use in
professional installation systems.

14. Description

The power units series AUP120/240/480R have been designed specifically
for microphone announcement and music diffusion in all PA installation
applications . The main features are as follows:

• One input/output balanced with XLR connector.

• One input/output unbalanced with RCA connector
• 4 Outputs : one output at constant impedance (8Ω) and three

outputs at constant voltage (25 – 70 – 100 V).

• A further output 100V available only for call and announcement

from microphone stand or telephone.

• Level indicator and overload led indicator.

• Input for one or more pre-amplified microphone stand BM100A

with priority function.

• One input for call from telephone central with VOX priority .

• Low & high tone control and general master.

• PA-HF Filter to be rear inserted.

• GROUND-LIFT rear selector.

• 24Vdc output with volume attenuator bypass during the

announcements .

• Main power selector (117 – 230 V ca).

• 24 Vdc for emergency power supply.


15. FUNCTIONS AND CONTROL

(1) Volume control

Such knob is used for output volume control.

(2) Led level indicator - Vu meter.

Gives an indication on signal level. For a correct amplifier use, the
volume level must be set between –20 dB e 0 dB indicated by ON
status of the first 5 LEDS , When the volume level makes only the
latest 2 LEDS ON status (+3 dB +6 dB), the output signal could be
distorted and the volume must be reduced
