12
EN
7. SUSPENDED CONFIGURATIONS
An additional subwoofer TT 808-AS can be placed below the first one with the use of two linking brackets�
1� Remove the four M10 screws from both the sides of the speakers�
2� Place the linking brackets on both sides (as shown in the picture) and screw them to the cabinet with the same M10 screws (and washers)
premoved earlier�
3� Place the second subwoofer in cardioid configuration and screw the bracket to it with the M10 screws provided�
NOTE: The same operations must be done on both sides of the speaker
NOTE: A maximum of two TT 808-AS can be suspended with the vertical bracket�
