10.3 Modality C – with one or more power unit per zone
Configuration suitable for big installations.
For such application, ZONE8 unit is set to allow the various zones microphone call not at all throughout
100 V audio signal commutation but commuting and bringing the audio signal to the different power units
LINE level inputs, power units set respectively per zone.
NB – Rear dip-switch n° 4 must be set on ON ( paragraph 11).
The connection configuration are per the following scheme.
