Thank you for choosing one of Proel products, and for your confidence towards our brand, synonymous of
professionalism, accuracy, high quality and reliability. All our products are CE approved and designed for
continuous use in professional installation systems.
2. DESCRIPTION
FREE50V3 unit is Proel answer to the continuous increase demand of audio autonomous portable
systems. System dedicated to voice and music sound reinforcement in ambient where there is no voltage
power supply source or cable connections difficulties due to length to be covered between the power
source and the unit to be powered.
FREE50V3 is a complete portable amplified system featuring high acoustic performance and is two ways
loudspeakers and 50W RMS amplifier equipped.
Such unit is suitable for voice sound reinforcement during conferences, exhibitions, sportive or religious
events etc.. FREE50V2 is VHF wireless microphone system and quartz equipped to ensure High
frequency stability level to allow orator free movements .
FREE50V3 is CD/DVD/MP3/USB/SD MMD card, AM/FM tuner, three microphone inputs, one AUX input
dedicated to external source one output for recording purposes or for twin acoustic cabinet piloting.
The internal rechargeable battery has been designed to ensure a good operating autonomy whilst the unit
weight has been contained to easy the unit transportable purposes.
FREE50V2 acoustic cabinet is trolley strong extensible handle equipped for portable need whilst the
dedicated flange set on bottom of the unit allows stand floor use.
Main functions:
N° 2 VHF palmar wireless microphone included in the standard unit package.
On request FREE50V3 can be supplied with lavalier microphone.
System 2 ways 8” woofer and 1”tweeter.
Two power supply options: Internal rechargeable battery – 230/117Vca.
CD/MP3/USB/SD MMD card player and AM/FM tuner.
Two microphone inputs , one AUX input and one high level LINE output.
Tone and Master output control.
3. FRONT PANEL – FUNCTIONS AND CONTROL
1 ON/OFF power switch
2 Connection for power supply cable
3 Main voltage value variation
4 Charge function indicator (when the 25% led flashes recharge the batteries)
5 Power On status/
battery discharge indicator
6 CD/DVD/MP3/USB/SD MMD card player – AM/FM tuner
7 VHF wireless microphone receivers module
8 XLR microphone inputs
9 Microphone inputs level control
10 Video Output
11 AUX input and AUDIO output
12 AUX input level control
13 CD/DVD player –Tuner level control
14 MASTER level control
15 Tone control
16 ECHO effect control
17 Connection for DC 18V
fig. 1
