36
GB
9.4 CLEANING OF THE WATER ENTRY FILTER
You should also clean filter B periodically. It is located
between the water tap and the water entry tube.
• Close water tap A.
• Unscrew attachment piece C, take out filter B, and clean
it thoroughly under running water.
• Put the filter back in its place and screw the water entry
hose on. Check that there are no water leaks.
9.5 CLEANING THE EXTERNAL DISHWASHER SURFACES
The external dishwasher surfaces (metal and plastic) must be cleaned regularly with a damp, soft cloth.
Never use acidic substances or abrasive detergents.
If you don’t use the appliance for long periods of time
In the event the dishwasher will not be used for a long period, proceed as follows:
• run the pre-wash programme twice
• remove the electric plug from the outlet
• disconnect the water supply tube
• leave the door slightly open to avoid the formation of bad odours.
9.3 CLEANING THE DRAINAGE PUMP
The pump may be accessed from inside the
dishwasher.
1. Always disconnect the plug from the mains
socket before cleaning the pump.
2. Unscrew the external filter 1 by turning it in an
anticlockwise direction (fig. 18).
3. Remove the stainless steel filter 3 (Fig. 20).
4. Remove the external microfilter 4 (Fig. 21)
5. Finally, remove the small insert Z from the left
part of the drainage hole in the base of the
appliance.
6. By placing your finger inside the hole, it is pos-
sible to rotate the pump propeller and eliminate
any blockages which may have occurred.
7. Replace the insert and the filters.
8. Plug the appliance back into the mains so-
cket.
Z
22
CAUTION: Do not forget to replace insert Z.
A
C
LA2505-040
B
23
