GB
26
The curved end of drainage tube , which is being supplied with your appliance, should be hooked
onto the edge of a sink or into a drainage pipe.
5.4 ELECTRIC CONNECTIONS
The appliance may only be connected to a properly installed electric outlet with
an earth (ground) contact. The connection must be carried out in correspondence
with existing laws and regulations and supplementary rules issued by the supplier
of electric power.
The voltage indicated in the technical data must match that of the location where the
appliance is installed.
Refer to the data plate for the correct size of the electrical plug.
If the appliance has no plug attached, it must be connected to the electricity supply by installing a
switch which is directly connected to the mains. This switch must ensure omnipolar disconnection
under overvoltage category III conditions.
5.2 WATER CONNECTION
The water supply tube , which accompanies the
dishwasher, makes it possible to connect the appliance to a
water tap with a 3/4” attachment.
During the installation, the following instructions must be
followed:
• Attach tube to the cold water tap .
• If the piping that the dishwasher will be connected to is
new or has been left unused for a long time, it is advisable
to let the water run for a few minutes before connecting
the water supply hose. This will prevent sand, rust or dirt
deposits from blocking the water supply hose filter.
• Make sure that the water pressure corresponds to the
range indicated on the data tag.
The appliance may be connected to the cold water system. It
must not be connected to the hot water system.
• The appliance must be connected to the water supply
using a set of new hoses; previously used hoses are
not recommended.
• Make sure the hoses are not excessively bent or bot-
tlenecked.
3
LA2505-040
A
B
C
C
C A
T
5.3 CONNECTION OF DRAINAGE WATER
T 4
A special siphon should be used to prevent bad
odours.
During the assembly, the following precautions
should be taken:
- the drainage tube must not be bent to avoid
blockages;
- the tube’s end, relative to the top surface of
the dishwasher (fig. 4), must be placed at a
height between 32 and 90 cm;
- the end of the tube must never be immersed
in water;
- the drainage tube must not be extended to
more than a maximum length of 1 metre.
The extension must have the same internal
diameter. Furthermore, the maximum height
at which the tube’s end can be placed (in the
case of an extended tube) must be reduced
from 90 to 50 cm.
- If you use a drainage pipe, make sure its internal diameter is not inferior to 4 cm.
