7. HOW TO USE THE SYSTEM
Accendere l’unità CONFD, il Dislplay (fig1. rif.5) indicherà la modalità di funzionamento in uso.
MODES OF OPERATION:
• FREE MODE
When this mode is selected, the display will read FREE MODE. In this mode, an unlimited number of participants
can speak simultaneously.
• LIMIT MODE
When this mode is selected, this display will show LIMIT MODE, plus the number of delegates that can speak
simultaneously. Once this number of delegates is reached, no further delegates will be allowed to intervene until
the number of active delegate stations again falls below this limit.
• FIFO MODE
When this mode is selected, the display will read FIFO MODE (First In-First Out), plus the number of delegates
who can speak simultaneously. In this mode, the CONFD keeps track of the order in which the delegate stations
are activated. Once the preset limit of simultaneous delegates has been reached, and a new delegate presses
the MIC ON/OFF key (fig. 3 ref. 8) on his microphone base, the FIRST station that was active when this limit
was reached will be made inactive, and the new delegate station will be activated.
Activation and Deactivation of previous Operating Modes
Using the MODE button (fig. 1 ref. 2), select the desired operating mode and press SAVE (fig. 1, ref. 4). If the mode
requires a numeric limit of delegates, this can be selected pressing the SET button (fig. 1, ref. 3) and pressing SAVE to
complete the setup.
FUNCTIONS:
• C. ONLY MODE
When this function is activated, the display will show “C.ONLY MODE” followed by the check mark “√”. When
deactivated, the display will show “X” beside this function.
C.ONLY MODE √:
When the PRESIDENT presses the PRIORITY key (fig. 3, ref. 9), all DELEGATES will be excluded, and the
DELEGATE microphones will not reactivate when their MIC ON/OFF key is pressed. These will remain
excluded until the PRESIDENT again presses the MIC ON/OFF key.
C.ONLY MODE X:
When the PRESIDENT presses the PRIORITY key (fig. 3, ref. 9), all DELEGATES will be excluded, but the
DELEGATE microphones will be reactivated normally when their MIC ON/OFF keys are pushed.
In either case (C.ONLY MODE “√” or “X”), the number of DELEGATES who can speak simultaneously will be
determined by the previously selected limit.
• A. OFF MODE
When this function is activated, the display will read A.OFF MODE followed by the check mark “√”. When
deactivated, the display will show “X” beside this function.
A.OFF MODE √:
All activated DELEGATE stations will be automatically disactivated after 45 seconds of inactivity. In order to
speak again the delegate will have to press MIC ON/OFF again (fig. 3, ref. 8)
A.OFF MODE X:
There are no time limits for the activated DELEGATE bases
This function does not affect the PRESIDENT base
