35
SPECIFICHE TECNICHE
Input Section
Inputs
2 electronically balanced
Input Impedance > 10 kohm
Maximum Input Level +20 dBu (+26 dBu with -6dB pad)
Input gain +6 dB to –30 dB in 0,2 dB steps
Input Connectors XLR F - XLR M to link
Digital Input AES/EBU (32 - 96 KHz sample rate converter inside)
Output Section
Outputs
6
Maximum Output Level +20 dBu
Output Gain +15 dB to –30 dB in 0,2 dB steps and mute
Output Connectors XLR M
Crossover Filters
Slopes
6 / 12 / 18 / 24 / 48 dB per octave
Type Bessel / Butterworth / Linkwitz-Riley
Delays
Max Delay time
600 ms on ALL In and Out
Min Delay Step 21 us
Parametric EQ filters
Maximum number of filters
5 per input / 5 per output
EQ Type Parametric, Notch, Shelf, Bandpass, res . hp/lp, Allpass
EQ Gain +15 dB to -15 dB in 0,2 dB steps
Q (bandwidth) 0,4 to 28,85 (3 to 0,05,1/20 oct . steps)
EQ freq 15,6 Hz – 22,62 kHz (1/20 oct . steps)
Dynamic EQ filters
Maximum number of filters
3 per input
Parameters EQ Param ., Shelf 6 / Freq . / Gain / Thre . / Time / Below-Above
Graphic EQ
EQ Type
28 band 1/3 oct .
EQ freq 31,5Hz - 16kHz 1/3 oct .
EQ Gain +12 dB to -12 dB in 0,2 dB steps
EXTRA FEATURES
RTA range
20Hz-20kHz 1/3oct .
RTA MIC input 15V phantom power
SPLM 4 scene /16 events for each scene
General
AD/DA conversion
24 bit
AD/DA latency 1,68 ms (analogue in – analogue out @ 48 KHz)
Sampling frequency 48 kHz
Internal processing 40 bit floating point
Frequency response ±0,5 dB 20 Hz-20 kHz
Dynamic range >110 dB 20 H-0 kHz unweighted
Distortion (THD) < 0,015% @ 1kHz, +18dBu
Display 192x32 LCD Graphic Display
Input / Output meters 4 LED
Remote control USB, RJ45 PRONET network
Dimensions 44 x 482 x 295 mm
Weight 4,1 kg (9 lb)
AC Power 100 to 240V ±15% @ 50/60 Hz
Consumption 35 VA
