4
MODEL Mi16 Connectors MODELLO Mi16 Conne ori
MONO INPUT CHANNELS CANALI INGRESSO MONO
Mic Input Sensi vity from -10 to -50 dBu
Balanced XLR-F
Sensibilità Ingresso Mic from -10 to -50 dBu
XLR-F Bilanciato
Mic Input Impedance 2 Kohm Impedenza Ingresso Mic 2 Kohm
Line Input Sensi vity from +20 to -20 dBu
Balanced Jack
Sensibilità Ingresso Line from +20 to -20 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
LO CUT 75Hz, 18dB/oct. LO CUT 75Hz, 18dB/oct.
EQ HIGH (shelving) ±15 dB @ 12KHz EQ ALTI (shelving) ±15 dB @ 12KHz
EQ MID (peaking) ±15 dB @ 2.5KHz EQ MEDI (peaking) ±15 dB @ 2.5KHz
EQ LOW (shelving) ±15 dB @ 80Hz EQ BASSI (shelving) ±15 dB @ 80Hz
STEREO INPUT CHANNELS CANALI INGRESSO STEREO
Line Input Sensi vity +4 / -10 dBu
Balanced Jack
Sensibilità Ingresso Line +4 / -10 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
EQ HIGH (shelving) ±15 dB @ 12KHz EQ ALTI (shelving) ±15 dB @ 12KHz
EQ LOW (shelving) ±15 dB @ 80Hz EQ BASSI (shelving) ±15 dB @ 80Hz
MASTER SECTION SEZIONE MASTER
MAIN MIX nom. out level +4 dBu Balanced XLR-M / Jack Livello nom. MAIN MIX +4 dBu XLR-M / Jack Bilanciato
C.ROOM nom. out level 0 dBu Unbalanced Jack Livello nom. C.ROOM 0 dBu Jack Sbilanciato
AUX nom. out level 0 dBu Unbalanced Jack Livello nom. AUX 0 dBu Jack Sbilanciato
2 - TRK nom. out level 0 dBu Unbalanced Rca Livello nom. 2 - TRK OUT 0 dBu Rca Sbilanciato
2 - TRK nom. in level 0 dBu Unbalanced Rca Livello nom. 2 - TRK IN 0 dBu Rca Sbilanciato
PHONES min. impedance 32 ohm
Stereo Jack
Impedenza min. PHONES 32 ohm
Jack Stereo
PHONES max. out level (2x) 193 mW Livello max. PHONES (2x) 193 mW
DIGITAL EFFECT PROCESSOR - PROFEX DIGITAL EFFECT PROCESSOR - PROFEX
Presets 256 (16 presets x 16 varia ons) Presets 256 (16 preset x 16 variazioni)
A/D and D/A converters 24 bit A/D and D/A converters 24 bit
DSP resolu on 24 bit DSP resolu on 24 bit
Controls LED display, DIAL, PEAK LED, TAP DELAY switch Controlli LED display, DIAL, PEAK LED, TAP DELAY switch
GENERAL SPECIFICATIONS SPECIFICHE GENERALI
Max level all outputs +22 dBu Livello Massimo Uscite +22 dBu
Crosstalk meas. at 1 KHz > 82 dBu Diafonia mis. a 1 KHz > 82 dBu
HUM & N unweighted < -93 dBu HUM & N non pesato < -93 dBu
THD+N at +4dB, 1kHz < 0,008 % THD+N a +4dB, 1kHz < 0,008 %
Dimensions (W x H x D) 420 x 368 x 87 mm Dimensioni (L x A x P) 420 x 368 x 87 mm
Weight 3.80 kg Peso 3.80 kg
POWER REQUIREMENTS ALIMENTAZIONE
Supply 110-240 VAC (±10%) 50 / 60 Hz
available with
Europe mains cord (Shucko plug),
US mains cord (NEMA 5-15P plug),
UK mains cord (BS1363 plug)
Alimentazione 110-240 VAC (±10%) 50 / 60 Hz
disponibile con
Cavo rete Europa (Spina Shucko),
Cavo rete US (Spina NEMA 5-15P),
Cavo rete UK (Spina BS1363)
Consump on 20 W Assorbimento 20 W
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
