DESCRIPTION OF THE APPLIANCE
4
4.1 GENERAL PARTS
4.2 TECHNICAL DATA
capacity (standard settings): ---
pressure of water supply system
minimum pressure: 0.05 Mpa
maximum pressure: 1 Mpa
CAUTION: the electrical specifications
are indicated on the data plate.
Parts of the dishwasher*
* Details may differ
depending on model and
market!
The product complies with the Low Voltage 2006/95/CE and
Electromagnetic Compatibility 2004/108/CE European Directives.
1) Grates of support
2) Upper sray-rotor
3) Electric cable
4) Water supply tube
5) Water drainage tube
6) Lower spray-rotor
7) Cutlery container
8) Filters
9) Rinse aid container
10) Container for detergent
11) Lower basket
12) Data tag
13) Drum handels (if provided)
14) Salt container
15) Upper basket
16) Long knives basket
(if provided)
17) Hook for door
closing mechanism
1
14
9 10
12
8
6
11
15
2
3
4
7
13
13
16
1
6
7
5
17
