54
EN
Acoustical specifications
Power section
Transducers
HL 6
Input/Output section
HL 35-S
Standard compliance
Physical specifications
Size
Shipping informations
Frequency Response (-10dB):
Max SPL @ 1m:
Horizontal coverage angle:
Vertical coverage angle:
Directivity index Q:
Nominal Impedance:
Power Handling:
Peak Power Handling:
Recommended Amplifier:
Protections:
Crossover Frequencies:
Compression Driver:
Nominal Impedance:
Input Power Rating:
Sensitivity:
Woofer:
Nominal Impedance:
Input Power Rating:
Sensitivity:
Input connectors:
Output connectors:
CE marking:
Cabinet/Case Material:
Hardware:
Handles:
Grille:
Color:
Height:
Width:
Depth:
Weight:
Package Height:
Package Width:
Package Depth:
Package Weight:
65 Hz ÷ 20000 Hz
131 dB
100°
10°
16
16 ohm
250 W RMS
1000 W PEAK
500 W
Dynamic Active Mosfet
900
1 x 1.0'' neo, 1.75'' v.c
16 ohm
50 W AES, 100 W PROGRAM POWER
109 dB, 1W @ 1m
2 x 6.0'' neo, 2.0'' v.c
200 W AES, 400 W PROGRAM POWER
16 ohm
92 dB, 1W @ 1m
Speakon
Speakon
Yes
PP Composite
Integrated array mechanics
2 on the rear panel
Steel
Black
237 mm / 9.33 inches
470 mm / 18.5 inches
377 mm / 14.84 inches
11 kg / 24.25 lbs
260 mm / 10.24 inches
550 mm / 21.65 inches
425 mm / 16.73 inches
12.4 kg / 27.34 lbs
40 Hz ÷ 140 Hz
134 dB
8 ohm
-
-
-
-
-
-
-
-
-
-
-
-
900 W
3600 W PEAK
1800 W
15'' neo, 4.0'' v.c
Yes
Speakon
Speakon
Baltic birch plywood
Integrated array mechanics
On side panels
Steel
Black
444.5 mm / 17.5 inches
480 mm / 18.9 inches
508 mm / 20 inches
28 kg / 61.73 lbs
530 mm / 20.87 inches
560 mm / 22.05 inches
525 mm / 20.67 inches
33 kg / 72.75 lbs
6. SPECIFICATIONS
