14
Thank you for choosing this Proel product and for trusting our brand, which strives to be synonymous with
professionalism, precision, high quality and reliability. All of our products comply with EC regulations regarding audio
equipment for continuous use.
2. DESCRIPTION
This professional active antenna splitter / booster splits the signal received from the two main “master” antennas to four
diversity channels. Combined with two antennas and four multi-frequency receivers, it forms a high-sensitivity four
channel receiving system.
The splitter has four 12VCD outputs for direct power supplying of the 4 wireless receivers
Product complies with CE regulations
3. FUNCTIONS AND PANNEL CONTROLS
Front Panel:
pict.1
1. ON/OFF
Press this button to turn on/off the device
2. ANTENNA
3. Power Light
