INDEX
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 3
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CONTROL PANEL (FIG.1) . . . . . . . . . . . . . . . . . . . . . 5
REAR PANEL (FIG.2) . . . . . . . . . . . . . . . . . . . . . . . . 5
CONNECTIONS (FIG.3) . . . . . . . . . . . . . . . . . . . . . . 6
CONFIGURATION EXAMPLE (FIG.4) . . . . . . . . . . . . 6
ENGLISH LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . 7
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 7
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
PACKAGING, SHIPPING AND COMPLAINT . . . . . . . 7
WARRANTY AND PRODUCTS RETURN . . . . . . . . . . 7
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . . 7
POWER SUPPLY AND MAINTENANCE . . . . . . . . . . 7
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . 8
OPERATING INSTRUCTIONS (FIG. 1 / 2 / 3 / 4) . . . 8
INDICE
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . 3
DIMENSIONI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PANNELLO DI CONTROLLO (FIG.1) . . . . . . . . . . . . . 5
PANNELLO POSTERIORE (FIG.2) . . . . . . . . . . . . . . . 5
CONNESSIONI (FIG.3) . . . . . . . . . . . . . . . . . . . . . . . 6
ESEMPIO CONFIGURAZIONE (FIG.4) . . . . . . . . . . . 6
LINGUA ITALIANA . . . . . . . . . . . . . . . . . . . . . . . . . 11
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 11
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . 11
CONFORMITÀ CE . . . . . . . . . . . . . . . . . . . . . . . . . . 11
IMBALLAGGIO, TRASPORTO E RECLAMI . . . . . . . 11
GARANZIE E RESI . . . . . . . . . . . . . . . . . . . . . . . . . 11
INSTALLAZIONE E LIMITAZIONI D’USO . . . . . . . . . 11
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 11
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . 12
ISTRUZIONI OPERATIVE (FIG. 1 / 2 / 3 / 4) . . . . . . 12
MIXER SECTION SEZIONE MIXER
MONO channels (3) MIC/LINE input (XLR/JACK combo) Canali MONO (3) ingresso MIC/LINE (XLR/JACK combo)
STEREO channels (1) LINE input (2 x RCA) Canali STEREO (1) ingresso LINE (2 x RCA)
Input Channel EQ HIGH: +/-15dB 10 kHz, LOW: +/- 15dB 100 Hz Equalizzatori Ingressi ALTI: +/-15dB 10 kHz, BASSI: +/- 15dB 100 Hz
Phantom power + 15 V (CH 1-3) Alimentazione Phantom + 15 V (CH 1-3)
Effect processor 24 bit digital - 16 Preset Processore effetto 24 bit digitale - 16 Preset
Effect presets HALL, ROOM, VOCAL and PLATE reverbs,
DELAY, REV + DELAY, REV +CHORUS
Impostazioni effetto riverberi HALL, ROOM, VOCAL e PLATE,
DELAY, REV + DELAY, REV +CHORUS
MONITOR out 1 x 3/4" jack Uscita MONITOR 2 x JACK 6,3mm
STEREO LINE out 2 x RCA Uscita STEREO LINE 2 x RCA
Main EQ 3-band EQ (HIGH, MID & LOW) EQ Main EQ 3-bande (HIGH, MID & LOW)
POWER OUT 1 x 3/4" jack (speaker 4 ohm min) Uscita SPEAKER 1 x jack 6,3mm (altoparlante min 4 ohm)
Metering 4-LED VU-METER Misurazione Livello 4-LED VU-METER
AMPLIFIER SECTION SEZIONE AMPLIFICATORE
Continuous Power 75 W @ 4 ohm (1 KHz, 1% THD) Potenza Continua 75 W @ 4 ohm (1 KHz, 1% THD)
Maximum Power 150 W @ 4 ohm (1 KHz, 1% THD) Potenza massima 150 W @ 4 ohm (1 KHz, 1% THD)
LOUDSPEAKER SECTION SEZIONE ALTOPARLANTE
System 2 Way - Vented Box Sistema 2 Vie - Bass Reflex
Low Frequency Device 6.5” woofer with 1" VC Altoparlante Bassi 6.5” woofer con 1" VC
High Frequency Device 1” neodymium tweeter Altoparlante Alti 1” neodymium tweeter
Angular Coverage 90° H x 60° V Copertura Angolare 90° O x 60° V
Impedance 4 ohm Impedenza nominale 4 ohm
Frequency Response 75 Hz - 20 kHz (-6 dB) Risposta in Frequenza 75 Hz - 20 kHz (-6 dB)
Max SPL 110 dB SPL massima 110 dB
Construction MDF with black antiscratch paint, metal grille Costruzione MDF colore nero antigraffio, griglia metallica
Pole holder 1 optionally attachable at bottom or at side Flangia per supporto 1 opzionale collegabile sotto o al fianco
GENERAL SPECIFICATION SPECIFICHE GENERALI
Power Supply 230 V~ / 120 V~ (switchable) 50/60 Hz Alimentazione 230 V~ / 120 V~ (commutabile) 50/60 Hz
Consumption 180 W Assorbimento 180 W
Dimensions (W x H x D) 200 x 320 x 220 mm Dimensioni (L x A x P) 200 x 320 x 220 mm
Weight 6.2 kg (13.7 lb) Peso 6.2 kg
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
