5
Introduction
XEOS is a series of speakers designed specifically for installed sound applications.
All of the models in the XEOS range utilize high-definition dome tweeters and high-efficiency woofers,
providing superior quality, full-range sound for a wide scope of installations where the sound system must
blend perfectly into any environment.
The three different surface-mount models available suit any kind of installed sound system, from paging and
background music in small-size environments, to full-range sound in bars, department stores and outdoor
venues, through to complex systems in large areas such as shopping halls and airports.
Technical Specification
Model XE35T XE55T XE65T
Speaker coax 3.5” woofer - 1” tweeter coax 5” woofer - 1” tweeter coax 6.5” woofer - 1” tweeter
Nominal Impedance 8 ohm 8 ohm 8 ohm
Max power rms/peak 15 W / 30 W 30 W / 60 W 40 W / 80 W
Nom. line power 1 / 2 / 4 / 7.5 / 15 W 1 / 2 / 5 / 10 / 30 W 2 / 5 / 10 / 20 / 40 W
70 V line impedance 4900/2450/1225/653/327 Ω 4900/2450/980/490/163 Ω 2450/980/490/245/123 Ω
100 V line impedance 10000/5000/2500/1333/667 Ω 10000/5000/2000/1000/333 Ω 5000/2000/1000/500/250 Ω
Line Input Voltage 70 / 100 V 70 / 100 V 70 / 100 V
Frequency Response 70 Hz - 20 KHz 70 Hz - 20 KHz 50 Hz - 20 KHz
S.P.L. 1 W / 1 m 85 dB 87 dB 87 dB
Dimensions 130 x 198 x 130 mm 181 x 240 x 172 mm 217 x 288 x 204 mm
Weight 1.8 Kg [3.97 lb] 2.7 Kg [5.95 lb] 3.7 Kg [8.16 lb]
INSTALLATION instructions valid for all models
1. WALL DRILLING AND FIXING THE BRACKET TO THE WALL
The wall drilling must be done as shown in the drawing for the model to be installed. Check if the
loudspeaker has enough space to orientate it in the desired direction and check that the fixing plugs
choosen are suitable to the type of wall and that they can hold up the weight of the speaker safely, then fix
the bracket to the wall.
2. CONNECTION
Connect the speaker to the amplifier following the correct polarity: Red (+) positive / Black (-) negative.
Following the same polarity for the whole audio system is very important for obtaining an optimal acoustical
result (see FIG. 2 - 3 - 4).
3. SPEAKER MOUNTING
Plug in the speaker into the bracket, aim it to sound a zone, then screw tightly the locking screws of the
cabinet.
ALWAYS MAKE SURE THAT LOUDSPEAKER IS PROPERLY LOCKED TO ITS BRACKET.
4. VOLTAGE SETTING
If the loudspeaker is connected to a constant voltage distributed line, set the switch to the correct voltage
(70V is usually the standard for America, 100V is usually the standard for Europe).
Always check that the line power amplifier is set for the same voltage.
5. LINE POWER SETTING OR LOW IMPEDANCE SETTING
Use the switch (1) to set the constant voltage line and the switch (2) to set the max power sent to the
loudspeaker: this setting depends on the max output power of amplifier and on the number of speakers
connected, according to the rule shown in FIG.3.
The same switch (2) can be used for selecting 8 W impedance, so the line transformer is excluded and the
loudspeaker can be connected to a low impedance amplifier (see the LOW IMPEDANCE SYSTEM connection
in FIG.4). In this case power capability of speakers and amplifier must be approximately the same for the
specified impedance.
CAUTION: the speaker can be damaged if it is erroneously set to 8 W and connected to a distributed
line.
english
