Thank you for choosing a Proel product, and for your confidence towards our brand, synonymous
with professionalism, high quality and reliability.
Description
Professional microphone stand ( BM100A pre-amplified version) high sensitivity condenser
microphone capsule, flexible stem, ON/OFF switch, and on/off switch*. Perfect for all PA
applications, microphone announcements. Powered by a separate adapter.
This product complies with CE directives.
Precautions
•
Before installing this unit please carefully read these instructions, and keep this owner’s
manual for future reference.
• WARNING: improper installation could irreparably damage the unit.
• Be careful that unit operation may not cause damage to people.
• Place the unit in a location protected from weather and far from water and moisture.
• Don’t place this unit close to heat sources (radiators, spotlights, amplifiers etc.)
•
Avoid any liquid entering inside the unit No user-serviceable parts inside. Refer servicing to
an authorized maintenance centre only
Installation
1. insert gooseneck connector to XLR plug present on microphone stand surface
2.connect the microphone stand to the present apparatus (mixer, amplifier ..ect)
using the cable included in the supply. If the unit microphone input is phantom powered, switch off
through the phantom supply selector rear set usually .
N.B before connecting the microphone switch off and reduce to zero the unit volume level.
3.feed the microphone stand thanks the power supply unit included in the supply
4.switch on firstly the microphone and adjust the volume level as required
5.to have an optimal sound reproduction, keep you mouth at a distance of 5 to 30 cm from the
microphone capsule.
6.chime tone circuit installation (BMGONG)
As in fig.1 remove the bottom cover –unscrew 4 presents screws , insert the circuit in the
appropriate connector A as per the illustration, block mechanically the circuit matrix with the fixing
nut
The pre-advice volume signal, activated through the push button, can be set thanks to the volume
control B
ATTENZIONE
Per evitare il rischio di shock elettrico non aprire il
prodotto.
Per prevenire rischi di incendio o di scosse elettriche
non esporre questo apparecchio ad acqua ed umidità
