Proel HPX8000 Manuale d'uso
Pagina 4
4
SETUP AND RACK MOUNTING (FIG. 1 / 2)
INSTALLAZIONE A RACK (FIG. 1 / 2)
LOUDSPEAKER CABLE
CAVO ALTOPARLANTE
COLD AIR
FRONTALE
8U OPEN RACK
10U closed RACK
RACK aperto 8U
RACK chiuso 10U
POSTERIORE
FRONT
REAR
FRONTALE
POSTERIORE (chiuso)
FRONT
REAR (closed)
ARIA FREDDA
COLD AIR
ARIA FREDDA
HOT AIR
HOT AIR
ARIA CALDA
ARIA CALDA
15 cm
6 inch
RECOMMENDED INSTALLATION
INSTALLAZIONE RACCOMANDATA
INSTALLATION WITH CLOSED BACK
INSTALLAZIONE CON RETRO CHIUSO
ENGLISH: Loudspeaker Line Losses (maximum permissible line lengths for 0.5dB losses, voltage or spl)
ITALIANO: Perdite di collegamento linee Altoparlanti (massima lunghezza possibile per perdite inferiori a 0.5dB, tensione o spl)
4 ohm load
8 ohm load
Wire section data
PROEL recommended cables
feet meter feet meter mm² AWG
2 wires
4 wires
2 wires Fire-resistant
4 wires Fire-resistant
75
25
150 50
4.0
12
HPC624
HPC644
HPC624FR
50
17.5
100 35
2.0
14
HPC620
HPC640
HPC520
HPC540
30
10
60
20
1.5
16
HPC610
HPC510
20
7.5
40
15
1.0
18
HPC605
this is a short extraction of the wide assortment of cables available from PROEL, please visit our website at www.proelgroup.com
FIG.1
FIG.2
