REAR PANEL (FIG.5) PANNELLO POSTERIORE (FIG.5)
EXAMPLE A ESEMPIO A
a2 a1
L
1+ 1-
4Ω minimum 4Ω minimum 4Ω minimum 4Ω minimum
set as STEREO for 4 indipendent channels
or
set as PARALLEL for 2 channel pairs
driven from a L/R audio channels
1+ 1- 1+ 1- 1+ 1-
R
a4 a3
