16
6) Finally, assemble the hopper on the jar correctly.
Firstly make the symbol “ ” on the hopper align
with the symbol “ ” on the motor unit and then
rotate the hopper clockwise until the tab on the
hopper edge lock into the groove on the motor unit
(See Figure 3). Make sure the hopper is assembled
in position properly otherwise the appliance will
not operate.
4) Place your juice container below the juice outlet
and residue container below the residue outlet.
Until now, the Juicer is ready for operating.
USING YOUR JUICER
1) Before attaching the power cord into the outlet, make sure the power switch is in the “O”
position, the power switch has three settings: “—” indicates “ON”, press the power switch
to“—” position to activate the motor and start making juice; “O” indicates “off” position,
press the power switch to “O” position to turn off the machine; “R” means reverse rotation,
which is only used when something is stuck and you need to unclog.
2) Make sure the juice container and the residue container are placed in position.
3) Cut fruits and vegetables into smaller pieces. For example, the carrots shall be cut into
thin slices with size of 15 mm × 15 mm before being put into the machine.
NOTE
A) Please remove any hard seeds before juicing.
B) It is not recommended to process coconuts or similar hard foodstuffs, since this may
damage the motor.
C) It is not recommended to process hard fruit or vegetable rich in fibre and starch, such as
sugarcane.
D) The peel and pits should be removed from oranges, lemons, grapefruits and melons.
4) Drop the prepared fruits or vegetables into the hopper and gently push the fruit down
into the grinding head using the food pusher.
5) Press the power switch to the “ON” position and the appliance starts to work. After few
Tab
Groove
Fig.3
