The right configuration of a Steadycam system implies the springs to be preloaded to see
that the parallelogram's sides will be
parallel to the ground in normal operating
conditions
(i.e. With arm correctly installed on the Vest and loaded with the sled).
If the arm's parallelograms shouldn't be parallel to the ground with fully preloaded springs,
it could be necesssary to replace the springs with the ones that have an higher spring
constant.
Please follow the load diagram attached to your X1 to create the best
spring combination in relationship to the weight to hold up. Arm X1
doesn't need an equal preloading of the 4 springs used.
