8
Note: when a flashing [LO] text appears, the batteries are near to be exhaust, to indicate that they must
be replaced as soon as possible.
5. BATTERIES COVER
Sliding down the lower part of the bodypack you can access to the battery inlet.
6. SET BUTTONS
Up and down buttons to set the transmitting frequency. IMPORTANT: be sure to not select the same
frequency on the two transmitters belonging to the same system because this will cause interferences
and malfunctioning.
7. GAIN
Using a PH1 Phillips screwdriver and rotating this trimmer is possible to optimize the gain of the
microphone before its signal is transmitted. Rotate it clockwise if you want an higher gain (speaking) or
rotate it counter-clockwise if you want a lower gain (singing).
8. SENSITIVITY
Select between the two input sensitivity:
•
L position = LOW usually used with instruments.
• H position = HIGH usually used for the Headset and Lavalier microphones like those supplied.
9. BATTERIES INLET
To operate the microphone needs 2 type AA alkaline batteries.
Note: the microphone is able to operate also with 2 Ni-MH rechargeable batteries, but in this case the
operating time is less.
10. CLIP
Clip to hook the Bodypack to the belt.
11. FREQUENCY
On the back side of bodypack an adhesive shows the frequency band of the transmitter.
TECHNICAL SPECIFICATION
WM600D – UHF PLL DUAL Channel Receiver Spurious Emission under limits EN 300422
RF Frequency Band UHF: 863-865 MHz Frequency Response 50 Hz – 15 KHz (±3 dB)
RF Sensibility -105 dBm Power Supply 2x1.5V AA alkaline bat
RF Image/Spurious Rej. >70 dB Dimensions 23.5 x 5 x 5 cm
RF Interference Reject. >70 dB
RF Frequency Stability ±0.002% WM6H – Bodypack UHF PLL Transmitter
THD Distortion <1% RF Frequency Band UHF: 863-865 MHz
S/N Ratio >105 dB RF Power <10 dBm
Frequency Response 50 Hz – 15 KHz (±3 dB) Modulation method FM (F3E)
Power Supply 13-15 V DC 500 mA RF Max deviation ±40 KHz
Dimensions 17.5 x 13.5 x 4.5 cm RF Frequency Stability ±0.002%
Spurious Emission under limits EN 300422
WM6M – Handheld UHF PLL Transmitter Frequency Response 50 Hz – 15 KHz (±3 dB)
RF Frequency Band UHF: 863-865 MHz Included Microphones: 2
RF Power <10 dBm HWM1 Headset Mic. Cond. Hypercardiod
Modulation method FM (F3E) LWM1 Lavalier Mic. Cond. Hypercardiod
RF Max deviation ±40 KHz Power Supply 2x1.5V AA alkaline bat
RF Frequency Stability ±0.002% Dimensions 10 x 6.5 x 3 cm
