INTRODUCTION

Thank you for choosing this PROEL product and for your trust in our brand, synonymous of professionalism,

accuracy, high quality and reliability. All our products are CE approved and designed for continuous use in

professional systems.

DESCRIPTION

The WM240 series of wireless microphones works in the 2.4 GHz free frequency range and it takes advantage

all the PROEL experience in the wireless technology for audio applications. The intelligent frequency hopping

can help to avoid interference effectively and ensures good performances and the maximum reliability. The

WM240 is the perfect tool for wireless audio applications in small and medium size environments, combining

performances, reliability and sturdiness and avoiding all the problems related to the interferences of digital

TV.
WM240 Digital Wireless Microphone system features 3 units: WM240 receiver, WM24M handheld

transmitter and WM24B body pack transmitter. The system is available in two different configurations:
WM240M :

WM240 + WM24M

WM240B :

WM240 + WM24B

Features:

- Operating Band: ISM 2.4 GHz free band

- GFSK digital modulation/demodulation

- Intelligent Frequency Hopping

- Automatic mute in case of bad quality transmission or high error code rate

- Memorization of matched devices

- Up to 2 systems usable in the same location (depending on the circumstances)

- Up to 25 meters (100 ft) transmit distance range in open place

WM240 RECEIVER

(see FIG. 1 at page 15)
1.

12-15VDC IN

Socket for the AC/DC adaptor connection: use only the adaptor supplied with the system.

2.

OUTPUT (UNBALANCED)

Unbalanced audio output with line level: connect it through a 6.3mm jack cable to a mixer input.

3.

ANTENNA

This is the receiving antenna. Raise it up during the use and, to obtain a better reception, place the

receiver away from other metal objects and distant no more than 25 m (100 ft) from the transmitter.

4.

STATUS LED

This BLUE LED shows the operative status of the receiver:
-

Low intensity: it indicates that the transmitter signal is not present, meaning that the transmitter is

turned off or it is not paired with the receiver.

-

High intensity: it indicates that the transmitter is on and it is paired with the receiver.

-

Intermittent Low and High intensity: the receiver is in pairing status (see below) and it is ready to be

paired with a transmitter.

5.

VOLUME

Volume potentiometer: set this control to a proper level that doesn’t overload the mixer input channel.

6.

PAIR BUTTON

This button is illuminated when there is a power DC. Press this button to start the pairing operation, in

order to couple the receiver with a transmitter (read carefully the following text box).
