4
MODEL Mi5 Connectors MODELLO Mi5 Conne ori
MONO INPUT CHANNEL 1 CANALE INGRESSO MONO 1
Mic Input Sensi vity from -10 to -50 dBu
Balanced XLR-F
Sensibilità Ingresso Mic from -10 to -50 dBu
XLR-F Bilanciato
Mic Input Impedance 2 Kohm Impedenza Ingresso Mic 2 Kohm
Line Input Sensi vity from +20 to -20 dBu
Balanced Jack
Sensibilità Ingresso Line from +20 to -20 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
EQ HIGH (shelving) ±15 dB @ 12KHz EQ ALTI (shelving) ±15 dB @ 12KHz
EQ LOW (shelving) ±15 dB @ 80Hz EQ BASSI (shelving) ±15 dB @ 80Hz
STEREO INPUT CHANNELS 2/3 and 4/5 CANALI INGRESSO STEREO 2/3 e 4/5
Line Input Sensi vity -10 dBv
Balanced Jack
Sensibilità Ingresso Line -10 dBv
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
MASTER SECTION SEZIONE MASTER
MAIN MIX nom. out level +4 dBu Balanced Jack Livello nom. MAIN MIX +4 dBu Jack Bilanciato
2 - TRK nom. out level 0 dBu Unbalanced Rca Livello nom. 2 - TRK OUT 0 dBu Rca Sbilanciato
2 - TRK nom. in level 0 dBu Unbalanced Rca Livello nom. 2 - TRK IN 0 dBu Rca Sbilanciato
PHONES min. impedance 32 ohm
Stereo Jack
Impedenza min. PHONES 32 ohm
Jack Stereo
PHONES max. out level (2x) 193 mW Livello max. PHONES (2x) 193 mW
DIGITAL EFFECT PROCESSOR DIGITAL EFFECT PROCESSOR
Presets 16 Presets 16
A/D and D/A converters 24 bit A/D and D/A converters 24 bit
DSP resolu on 24 bit DSP resolu on 24 bit
Controls 16-posi on rotary switch, PEAK LED, MUTE
switch
Controlli commutatore 16 posizioni, LED PEAK, tasto
MUTE
GENERAL SPECIFICATIONS SPECIFICHE GENERALI
Max level all outputs +22 dBu Livello Massimo Uscite +22 dBu
Crosstalk meas. at 1 KHz > 82 dBu Diafonia mis. a 1 KHz > 82 dBu
HUM & N unweighted < -93 dBu HUM & N non pesato < -93 dBu
THD+N at +4dB, 1kHz < 0,008 % THD+N a +4dB, 1kHz < 0,008 %
Dimensions (W x H x D) 172 x 225 x 75 mm Dimensioni (L x A x P) 172 x 225 x 75 mm
Weight 1.0 kg Peso 1.0 kg
POWER REQUIREMENTS ALIMENTAZIONE
Supply 18VAC 500mA
use only supplied AC/AC ADAPTER
Alimentazione 18VAC 500mA
usare solo AC/AC ADAPTER incluso
Mains Supply Voltage,
see label on the AC/AC
ADAPTER, available for: 110-120 VAC (±10%) 50 / 60 Hz (US plug) Tensione di Rete,
vedi l'e che a sull' AC/
AC ADAPTER, disponibile
per: 110-120 VAC (±10%) 50 / 60 Hz (US plug)
230-240 VAC (±10%) 50 / 60 Hz (EU plug) 230-240 VAC (±10%) 50 / 60 Hz (EU plug)
240 VAC (±10%) 50 / 60 Hz (UK plug) 240 VAC (±10%) 50 / 60 Hz (UK plug)
Consump on 17 W Assorbimento 17 W
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
