21
7. PACKAGE CONTENTS
AMI63
Power cable
Instruction Manual
8. TECHNICAL FEATURES
Model AMIX63
INPUT CH1
~CH6
MIC input Electronically Balanced
Gain 0 dB to -50 dB
Max. Input +18dBu (line/mic)
S/N ≥85 dB
Phantom power 16~19 V DC
Line Input Electronically Balanced
Frequency Response 20Hz-22KHz +/-3dB
Sensitivity 0 dBu
INPUT CH7 ~CH9
Line Input Unbalanced
Sensitivity 0 dBu
Max. Input +20dBu
S/N ≥105 dB
Frequency Response 20Hz-22KHz +/-3dB
T.H.D. ≤0,03% @ 1KHz
Input Impedance 1,4 KOhm Micro
10KOhm Line
Output Impedance 1 KOhm REC OUT
120 Ohm LINE OUT/MONO OUT
Tone Control High: ±15dB @ 12KHz
Mid: ±12dB @ 2,5KHz
Low: ±15dB @ 80Hz
Power supply
230VCA 50/60Hz
117VCA 50/60Hz (AMIX63117V)
Power Consumption 18W
Input Connectors CH1~CH6: COMBO (XLR + JACK 6,3)
CH7~CH9: 2 x RCA
Output Connectors XLR Male
Dimensions (WxHxD) 483x44x195 mm
1U Rack standard 19”
Weight 2,9Kg
This product complies with Directive 89/336/EEC (Electromagnetic Compatibility)
and later changes 92/31/EEC and 93/68/EEC, according to the following standards:
EN 50082-1:1997, EN 55013:1990, EN 55020:1994
furthermore, it complies with Directive 73/23/EEC (Low Voltage)
and later changes 93/68/CEE, according to the following standard:
EN 60065:1998
Proel SpA maintains a policy of constant research and development, therefore we reserve the right to apply improvements to existing equipment
without prior notice. REV. 01 38/12
