• To obtain good speakers wire contacts, please tighten the screw terminals firmly.
• For safety reason, don’t defeat the grounding connection. Grounding is useful for user
safety.
• Use only connectors and accessories suggested by the manufacturer. .
• This unit should be placed in a rack (see INSTALLATION) and kept far from:
Wet places
Direct exposure to heat sources (like sun light)
Non properly ventilated places
• Disconnect the power cord during storms or when the unit is not used.
• In order to prevent fire and electric shock risks, it’s necessary to keep the unit far
from sprinkling and drops. Please don’t put cups, vases or other object containing liquids
over the unit. In case of interferences from source signal, THD value will raise over 10%.
Don’t place this unit in a bookshelf o in other places with small room.
• PROEL S.P.A. is not responsible for any damage that occurs due to a wrong unit
installation.
Thank you for choosing one of Proel products, and for your confidence towards
our brand, synonymous of professionalism, accuracy, high quality and reliability.
All our products are CE approved and designed for continuous use in
professional installation systems.
2. DESCRIPTION
The new AMIX4Z is a one 19” standard rack unit compact mixer featuring 4 Ø
6.3 mm TRS stereo jack line inputs and 1 XLR 3-pole microphone input with
Phantom 18Vdc power supply, especially designed for multi-room applications
and line/microphone signals monitoring. The 5 independent channels can be
individually controlled by front volume potentiometers and individually
addressed to the 4 outputs (thanks to the A, B, C, D individual postfader
switches). The master outputs (A, B, C, D) are controlled by the general volume
potentiometer. AMIX4Z inputs/outputs are monitored by a led bar featuring a
clipping indicator. It also features a stereo headphones ouput (Ø 6.3 mm TRS
stereo jack) with volume potentiometer to monitor output channels mix. The 4
MASTER outputs are supplied by means of 3-pole XLR parallel connected to a
Ø 6.3 mm TRS stereo jack.
