CONTROL CONTROL PANEL
1 BUTTONS:
- ON / OFF
- Temperature control
- SUPER mode activation
2 GREEN LED MINIMUM POSITION
3 GREEN LED MEDIUM POSITION
4 GREEN LED MAXIMUM POSITION
5 YELLOW LED super MODE
6 RED LED ALARM FUNCTION (FREEZER)
DESCRIPTION OF THE APPLIANCE
The appliance consists of two cells:
- A fridge (lower part) for storing fresh food and drinks
- A freezer (upper part) for long-term storing of frozen
products and for freezing fresh products.
BEFORE STARTING THE FRIDGE
When cleaning the internal compartments and accessories,
follow the instructions reported in chapter “ Cleaning ”.
CONNECTING THE APPLIANCE TO THE MAINS SUPPLY
Check that the mains voltage corresponds to that indicated
on the appliance’s rating plate and that the mains socket is
equipped with an earth connection.
AWARNING! If the appliance is switched off then
immediately back on again, the compressor will
start to operate after approximately 10 minutes.
This is normal.
START-UP AND CONTROL OF REFRIGERATOR COMPARTMENT
On insertion of the plug in the mains socket, if the green led
(S2) (minimum position) does not light, this means that the
appliance is switched off. To start up the appliance, press
button T1 for at least 0.5 seconds. To interrupt operation,
press T1 for at least 4 seconds. On power-up, operation is
indicated by illumination of the green led (S2) (minimum
position) . If the freezer compartment is warm, the red led
(S6) (alarm) starts to fl ash, and turns off automatically when
the freezer compartment reaches the temperature of -12°C .
- Temperature programming and control: 3 different
temperatures can be selected, as indicated by the 3
green leds (S2-S3-S4). To change settings, press but-
ton (T1); on each click the illuminated led turns off and
the next one fl ashes for 4 seconds according to the
sequence S2-S3-S4 - S5. The new setting is saved
at the end of the fl ashing phase. Activation of SUPER
mode (S5) is by means of button (T1) after which the
yellow led (S5) is permanently lit.
The programmed functions are memorised also in
the event of a power failure or when the appliance is
disconnected.
Using the fridge compartment
1 2 3 4 5 6
A
B
T1 S3 S5
S2 S4 S6
2 1 T1
S2 S6
