GB/MT GB/MT GB/MT GB/MT
Using the USB socket 3
If you would like to use a device which can be
operated using a USB charging cable, first con-
nect the USB charging cable to the device. Insert
the USB adapter of the charging cable into the
USB socket of the universal car charger
1 .
Ensure before using the universal car charger that
the required current of the device to be operated
does not exceed 1000 mA (= 1 A).
Using the coaxial socket 4 and the USB
socket 3 simultaneously
If you would like to connect two devices simulta-
neously, ensure before use that the total current of
the devices to be operated does not exceed
1000 mA (=1 A).
Insert the universal car charger into a correctly in-
stalled car cigarette lighter socket with an operating
current between 12 V and 24 V. The control lamp
2 shows that the universal car charger is in use.
Following the successful charging of your device,
disconnect your device from the universal car
charger.
Remove the universal car charger from the socket.
Replace the fine fuse
The input of the universal car charger 1 is equipped
with a fine fuse 6 to protect against overloading. If
this fine fuse is burnt through, the control lamp 2 will
not illuminate - following insertion of the universal car
charger into a ready-to-use car cigarette lighter
socket. You must replace the fine fuse.
In order to do so, screw the front cover 5 off,
remove the fine fuse, and replace it with a new
fine fuse (refer to “Technical data“) (Fig. B). Ap-
propriate fine fuses can be purchased in elec-
tronic specialist shops or alternatively in radio
and television shops.
Cleaning and Storage
Disconnect the device before cleaning and when
not in use from the 12/24 V connection to avoid
the risk of an electric shock.
Clean with a soft, lint-free cloth!
The temperatures inside a vehicle can reach ex-
treme values in summer and winter. Consequently,
to avoid damage to the device, you should not
store it in the vehicle.
Store the device somewhere clean, dry, free of
dust and out of direct sunlight.
Disposal
The packaging is made of environmentally
friendly materials, which may be disposed
of through your local recycling facilities.
Contact your local community or municipal adminis-
tration for more details on how to dispose your worn-
out product.
Never dispose of the product/the
article in your regular household
waste.
Dispose of the device/article at an authorised dis-
posal centre or at your local council disposal facility.
Observe the applicable regulations. In case of doubt,
please contact your waste disposal centre.
Warranty
The device has been manufactured to strict quality
guidelines and meticulously examined before deliv-
ery. In the event of product defects you have legal
rights against the retailer of this product. Your legal
rights are not limited in any way by our warranty de-
tailed below.
The warranty for this device is 3 years from the date of
purchase. Should this device show any fault in materi-
als or manufacture within 3 years from the date of pur-
chase, we will repair or replace it – at our choice – free
of charge to you.
The warranty period begins on the date of purchase.
Please keep the original sales receipt in a safe location.
This document is required as your proof of purchase.
This warranty becomes void if the device has been
damaged or improperly used or maintained.
The warranty applies to faults in material or manufac-
ture. This warranty does not cover product parts
subject to normal wear, thus possibly considered con-
sumables (e.g. batteries) or for damage to fragile parts,
e.g. switches, rechargeable batteries or glass parts.
Scope of delivery
1 In-Car Charger
11 Charging adapters
1 Instructions for use
Safety notices
PLEASE READ THE INSTRUCTIONS FOR USE
PRIOR TO USE! PLEASE KEEP THE INSTRUCTIONS
IN A SAFE PLACE!
Check the product for damage before use. Never
use a damaged product.
This device may be used by children age 8 years
and up, as well as by persons with reduced physi-
cal, sensory or mental capacities, or lacking
experience and/or knowledge, so long as they
are supervised or instructed in the safe use of the
device and understand the associated risks. Chil-
dren should not be allowed to play with the de-
vice. Cleaning and user maintenance should not
be performed by children without supervision.
Only suitable for indoor use: Do not expose the
product to direct sunlight or moisture!
Only plug the appliance into sockets that are
easily accessible, so that you can unplug it easily
in case of an emergency.
Do not operate the appliance if you are driving a
car or other vehicle. This presents a source of
danger in road traffic.
Start-up
IMPORTANT! You can leave the motor on or off
when using the universal car charger. Be aware that
the battery of car might become low because the de-
vice still consumes power when the motor is off. Dis-
connect the device completely from the power supply
if you are not intended to charge your mobile.
Attention: Do not switch the ignition on or off dur-
ing the charging process, as this can lead to differ-
ences or peaks in the power supply.
Using the coaxial socket 4 and one of the
supplied charging adapters
Connect the device to be charged to the coaxial
socket using one of the charging adapters sup-
plied
7 – 17 (Fig. C). Ensure that the 5 V volt-
age provided in the coaxial socket 4 can be
used with your device.
In-Car Charger
Intended use
The universal car charger is exclusively intended for
the charging of electronic devices with a charging
voltage of 5 V and for operating USB charging
devices. 11 adapters (refer to “Parts description“) are
included to charge electronic devices using a charg-
ing voltage of 5 V. You can use the universal car
charger in the car cigarette lighter socket, which pro-
vides input voltage (noted under “Technical data“).
The universal car charger is not intended for
commercial use.
Parts description
1 In-Car Charger
2 Control lamp
3 USB socket
4 Coaxial socket Ø 3.5 mm
5 Front cover
6 Fine fuse (F2AL 250 V)
7 Charging adapter Mini-USB
8 Charging adapter Micro-USB
9 Charging adapter Samsung TM D600 (S1)
10 Charging adapter Samsung TM G600 (S2)
11 Charging adapter Samsung TM D800 (S3)
12 Charging adapter Nokia TM 3.5 mm (N1)
13 Charging adapter Nokia TM 2 mm (N2)
14 Charging adapter LG TM KU990 (L1)
15 Charging adapter Sony Ericsson TM K750i (E2)
16 Charging adapter Playstation ® Portable (PSP)
17 Charging adapter Nintendo TM DS (NDS)
Technical data
Input voltage: 12–24 V ,
max. 800 mA
Output voltage
(coaxial socket Ø 3.5 mm):
5 V ,
max. 1000 mA
Output voltage (USB): 5 V ,
max. 1000 mA
Total of output power: max. 1000 mA
Fine fuse: F2AL 250 V
Operating temperature: 5°C–45°C
OWIM GmbH & Co. KG
Stiftsbergstraße 1
D-74167 Neckarsulm
Model no.: 106898-14-01
Version: 01 / 2015
Versione delle informazioni
Last Information Update: 01 / 2015
Ident-No.: 106898-14-01012015-IT
