14
FREEPACK812 - TECHNICAL SPECIFICATION
MIXER Section
MONO inputs 6 x MIC/LINE IN (XLR/JACK)
STEREO inputs 2 x LINE IN (JACK/2xRCA/mini-jack)
Input EQ 2-band EQ (HIGH + LOW)
Internal Effect 16 Preset DIGITAL multieffect with 1 parameter
Outputs 2x SPEAKER OUT (JACK)
Metering 2x 10 LED VU-meter
MULTIMEDIA Section
Player Type USB / SD / BLUETOOTH player
Compatible File Formats WAV, MP3, WMA
Control Interface LCD display, REMOTE control
AMPLIFIER Section
Amplifier Type Class D with SMPS (Switching Mode Power Supply)
Maximum Output Power 2x 500 W @ 4 ohm (1 KHz, 1% THD)
Frequency Response 20 Hz - 20 KHz
LOUDSPEAKER Section
Loudspeaker System 2-way system vented
High Frequency Device 1" horn loaded compression driver
Low Frequency Device 8” x 12” elliptical woofer
Angular Coverage 90° H x 60° V
Impedance 8 ohm
Frequency Response 50Hz - 20KHz, -10dB
SPL 1W 1m 96 dB
Construction Polypropylene Cabinet, Metal Grille
Handles 1 top
Pole Holder 1 bottom
GENERAL Specifications
Dimensions (W x H x D) System: 81 x 24.5 x 61 cm / Speaker: 31 x 24.5 x 57.5 cm /
Mixer: 41 x 24.5 x 61 cm
Weight System: 28 Kg / Speaker: 9Kg / Mixer: 10Kg
Power Supply 230 / 115 V~ (switchable) 50 / 60 Hz
Power Consumption 700 W
